Dirt Water Pump

GE-DP 5220 LL ECO

Item no.: 4170780 EAN: 4006825598780
  • 2-in-1 combi pump – clear water and waste water with one device
  • Clear water: Flat suction up to 1 mm residual water level
  • Waste water: up to 20 mm particle size in coarse waste water
  • Pump start from 10 mm water height possible
  • Patented suction level regulation through simple rotary movement
  • Infinitely height-adjustable float switch
  • High-quality ceramic/rubber mechanical seal for long service life
  • Ergonomic carrying handle with integrated hanging eyelet
  • Easily accessible hose connection on the top of the pump
  • Hose connection approx. 47.8 mm (G 1 ½) AG
  • Universal adapter for 25/32 mm hoses and 33.3 mm (G 1) AG
  • Housing made of impact-resistant plastic
  • Overload switch
  • Automatic mode for desired water level (float switch)
  • ECO power: more flow rate, less power consumption
See more information
einhell-expert-dirt-water-pump-4170780-productimage-101
Article description

The 2-in-1 combi waste water pump GE-DP 5220 LL ECO is the robust, powerful and reliable helper from the Einhell ECO power series. The combi pump is particularly suitable for the rapid pumping of ponds, excavation pits or flooded basement rooms and can be used for clear and waste water up to 2 cm particle size. The combined waste water pump impresses with state-of-the-art technology, full power and optimum energy efficiency – with a power consumption of only 520 watts, this powerful submersible pump delivers up to 13,500 litres of water per hour. The infinitely variable float switch offers the choice between continuous operation and a preselected switch-on and switch-off level. The pump can be started from 10 mm water height. With the patented suction level regulation by a simple rotary movement, a quick adjustment of the desired function can be made. A pump for two tasks: flat suction up to 1 mm residual water level in clear water operation or suction of waste water with a particle size of up to 20 mm. The extremely robust pump housing and the high-quality ceramic/rubber mechanical seal reliably withstand even hard drainage tasks and guarantees a long service life. Thanks to the practical, ergonomic carrying handle, this 2-in-1 combi pump is quickly and easily ready for use anywhere.

Technical details

Max. delivery height7.5 m
Max. delivery pressure0.75 bar
Max. delivery rate13500 l/h
Max. foreign body size20 mm
Max. immersion depth7 m
Max. water temperature35 °C
Min. water level pump start10 mm
Power520 W
Power cable length10 m
Pressure connection type47,8 mm (G11/2 AG)
Shallow suction up to1 mm
Stepless-float-switch

Stepless float switch

The infinitely adjustable float switch automatically switches the pump on and off at a previously set water level.

High-quality-seal

High-quality seal

The high-quality and robust mechanical seal inside the pump ensures a long service life, even under heavy loads.

Universal-connection

Universal connection

The pump housing is made from impact-resistant plastic. In addition, the universal connection is attached to the top and can be reached at any time.

Simple-transport

Simple transport

Thanks to the practical, ergonomic carrying handle, this 2-in-1 combi pump is quickly and easily ready for use anywhere.

What type of pump is it?

The waste water and clear water pump GE-DP 5220 LL ECO is a pump that is either completely or partially in the water.

What is the waste water and clear water pump suitable for?

For drainage (e.g. pools, basement rooms), extraction and transport of waste water and clear water.

Can the pump be used for garden watering?

No – only to a limited extent as the delivery pressure is not sufficient for lawn sprinklers.
